Vanguard 363RT

Vanguard 363RT (Opera 400)

NOTE: Information on this page is actually about OPERA, the European version of this organ. Specifications and photographs of the North American version (Vanguard) are not yet available from the supplier.

  • Slide title

    Write your caption here
    Button

  • Slide title

    Write your caption here
    Button

  • Slide title

    Write your caption here
    Button

  • Slide title

    Write your caption here
    Button

Opera 400 Description

With its elegantly designed solid wood cabinet, three manuals and a 32-note pedalboard, the Opera 400 is the ideal organ for those who want to play without compromise. Especially suitable for larger venues, it will be able to satisfy even the most demanding organists thanks to the innovative Physis Plus technology and all the improvements made by Viscount after years of study.

Product Brochure

Opera 400 Features

  • 3 Manual (Tracker Touch)
  • Swell Expression and Crescendo Shoes
  • 55 Organ stops + 8 Orchestral: Pedal (12), Manual I (11), Manual II (15), Manual II (17)
  • 15 Couplers
  • 1000 Memory Locations, 9 Memory Banks, Total 9000 Memories
  • Piston Sequencer
  • Two Tremulants
  • Reverb: 16 Presets

Opera 400 Stop List

Pedal: 12 voices, I/8, II/8, III/8, III/4

Manual I: 11 voices, Tremulant, I/16, III/16, III/8, III/4

Manual II: 15 voices ,Tremulant, III/16, III/8, III/4, I/8

Manual III: 17 voices, Tremulant, III/16, III/8 Off, III/4


Alternative Organ Voices: 5 (or more) on each tab

Alternative Orchestral Voices: 30 or more on each orchestral tab

Temperments: 19 Historical + 4 user programmable


Modern, Broque, Romantic, Symphonic, English Cathedral


Please see brochure for stop list.

Opera 400 Dimensions/ Cabinet

Height (excluding music desk) 127 cm - 50”

Height (including music desk) 151.5 cm - 59.6”

Width 164.1 cm - 64.6”

Depth (excluding pedal board) 70.5 cm - 27.7”

Depth (including pedal board) 111.2 cm - 43.7”

Weight 195 Kg - 430 Lbs


Dark oak, light oak


Opera 400 Audio

MIDI In / Out

Aux In / Out

Headphones

USB


Internal Aplifiers: 6 channels Class-D amplifier - 150W per channel

Internal Speakers: 10 total / 4 tweeter / 4 mid-range / 2 x 10" woofer

Channel Assignable: Reverb LR / General / Sub

Return to Vanguard
